FQM1-8801N-ACST 50MM

For PDF Spec:

For STEP File:

Type:

Inductive

Shape:

Square

Dimensions:

50 mmx8 mmx8 mm

Sensing Range:

1 mm Range

Mounting Style:

Shielded

Output Type:

NPN

Output Function:

Normally Open

Connection:

3 Pin Quick Disconnect

Connector:

M8 Connector

Housing Material:

Nickle Plated Brass

Sensing Face Material:

PBT Plastic

IP Rating:

IP67

Operating Temperature:

-25 C - +70 C

Operating Voltage:

10-30 V DC

Current Consumption:

<10 mA

Leakage Current:

<0.01 mA

Max Current:

200 mA

Overload Trip Point:

>220 mA

Surge Current:

-

Short Circuit Protected:

Yes

Reverse Polarity Protected:

Yes

Switching Frequency:

2Khz

Response Time:

0.1ms

EMC Rating:

RFI>3V/m / EFT>1kV / ESD>4Kv (contact)

Shock/Vibration Rating:

IEC 60497-5-2 Part 7.4.1&7.4.115

Weld Field Immune:

No

Weld Spatter Resistant:

No

Description:

Rectangular, 1 mm, NPN, Normally Open

Matching Cable:

C-FS3TZ-V075 (Straight Connector) / C-FA4TZ-V075 (Angled Connector)
